Block 22mm double - Tersma masters range

Tersma Sailing Products

Composite Ball Bearing Blocks

Composite ball bearing blocks are engineered for competitive sailing. The high strength composite sideplates are to provide top performance of working loads. The excellent weather-ability protects blocks from breaking down for any sailing conditions. Available in comprehensive range of sizes for different rope diameters and configurations. our blocks are beautiful in design, but simple in use.

22mm Double Block - BB-2203F
Sheaves:         22mm

Maximum line:  6mm

Weight:            28g

Max. working load: 200kg

Max breaking load: 780kgs

MATERIALS

• Sheave: self-lubricant acetal composite
• Ball Bearing: self-lubricant acetal composite
• Sideplates/frames: reinforced glass fiber Nylon composite with UV stablized
• Shackle: Forged  Grade 316 stainless steel

APPLICATIONS

• Mainsheet system, jib and spinnaker sheets on dinghies to 5m(16ft)
• Halyard, vang and backstay on boats to 8m (26ft)
• Control lines on boats of all sizes
